NS Bikes Define 130 2 29er Mountain Bike 2019 - Trail Full Suspension MTB
One of our favourite bikes in the range, the 29-er Snabb now goes carbon! The frame of this bike is not just a fancy version of the alloy workhorse. We worked hard to make sure we really are taking things to the next level. To start with, the industrial design was conceived by the guys who made the Eurobike Gold Award winning Rondo Ruut. It features unique semi-internal cable routing - the lines are elegantly hidden away, but there is none of the hassle that is involved with standard internal routing. The frame has adjustable geometry: you can adjust the reach via offset headset caps and adjust the height of the BB via interchangeable shock mounts (it’s even possible to change the the travel by swapping the shock and shock mounts). Big sealed pivots keep the frame stable and guarantee long periods of smooth, service free function. There are a few things that we did “borrow” directly from the Snabb - and that is the kinematics of the 4-bar suspension that everyone loves (Pinkbike: "There is so little pedal-induced bobbing at play here that it sort of boggles the mind”), progressive geometry and all-round fun factor.
Arguably one of the most universal bikes in the range. Rip up and down mountains all day, every day. The carbon version of the highly praised Snabb can really do it all but the Define takes things to the next level. This beautiful frame is light and tough and has lot's of unique features including adjustable reach and BB height. One of things we like a lot are the semi-integrated cable guides - a practical and elegant solution of the internal / external cable routing dilemma. Oh and don't be fooled by the “shortness” of it's travel. It really feels like it has much more than the quoted numbers. At the same time, the climbing capability of this bike is absolutely amazing.
We recommend the M size for 170 – 182cm and the L size for riders over 180cm.
Key Features:
- Brand new full carbon frame
- Progressive geometry with 44 mm fork rake
- Adjustable reach and BB height
- Semi internal cable routing
- 140/130 front/rear travel
- Fox Performance suspension
- SRAM GX 1x12 drivetrain
- 35mm NS Bikes cockpit
- X-Fusion dropper post
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | NS Define, carbon firbe w/ 130mm travel, custom reach adjustable offset cups (+/- 10mm) |
| Fork | Fox Performance 34 Float Grip, 140mm travel, Sweep Adj, 15x110mm Boost, 1.5 tapered steerer tube, 44 offset |
| Rear Shock | Fox Performance Float DPS 3pos-Adj Evol LV Trunnion 185x55 |
| Headset | NS custom tapered 1&1/8"-1.5" IS42/IS52 reach adjustable offset cups (+/-10mm), sealed bearing |
| Stem | NS Quantum Lite 35, 45mm |
| Bars | NS Bar 780mm, 20mm rise |
| Front Brake | Sram Guide T, 180mm |
| Rear Brake | Sram Guide T, 180mm |
| Brake Lever | SRAM Guide T |
| Rear Mech | Sram GX Eagle type 3 12spd |
| Shifters | Sram NX, 12spd |
| Speed | 12 |
| Rims | Octane One Solar 29”, 32h, tubeless ready |
| Front Hub | NS Rotary 15 Boost 15x110 disc (sealed bearings) |
| Rear Hub | NS Rotary Cassette 148x12mm Boost (sealed bearings) |
| Spokes | Spokes w/14mm nipples |
| Front Tyre | Schwalbe Nobby Nic 29x2.35 |
| Rear Tyre | Schwalbe Nobby Nic 29x2.35 |
| Seat Post | X-Fusion Manic internal 125, 150mm |
| Saddle | Octane One Crit, CrMo hollow rails |
| Chainset | Truvativ Descendant DUB 170mm 32t |
| Bottom Bracket | SRAM DUB BB92 |
| Chain | Sram, 12 spd |
| Cassette | SRAM PG-1230,12spd 11-50t |
| Pedals | Basic Resin Flat |
| Weight | 13.8kg |
Mountain Bike Size Chart
|
Height
|
Bike Size
|
Mountain Bike Size
|
|
4’8” – 5’1”
143 – 155 cm
|
XXS
|
13” (33 cm)
|
|
5’1” – 5’4”
155 – 163 cm
|
XS
|
15” (38 cm)
|
|
5’4” – 5’7”
163 – 170 cm
|
S
|
16” (41 cm)
|
|
5’7” – 5’10”
170 – 178 cm
|
M
|
18” (46cm)
|
|
5’10” – 6’0”
178 – 183 cm
|
L
|
19” (48cm)
|
|
6’0” – 6’3”
183 – 191 cm
|
XL
|
20” (51 cm)
|
|
6’3” – 6’5”
191 – 196 cm
|
XXL
|
21” (53 cm)
|
|
6’5” – 6’9”
196 – 205 cm
|
XXXL
|
22” (56 cm)
|
* Mountain bikes are sized differently to road bikes. Typically, they are sized in inches as the first MTBs were produced in the USA. European brands like Lapierre and Haibike like to use centimetres for all their bikes. The measurements of their mountain bikes doesn’t match their road bikes but are like a simple conversion from the inches measurement. This is why we have included cm measurements in brackets for the Mountain bike column.
Read our bike size guide for more information on sizing.
