(no reviews)Product ID: 259282
Cube Kathmandu Pro Trapeze 2023 - Touring Bike
We designed the Kathmandu Pro to have everything you need and nothing that you don't. From the redesigned Integrated Carrier to the full-length mudguards, front and rear lights and CUBE FM kickstand, it's the practical everyday companion that's rugged enough to take on longer trips, too. A Suntour air suspension fork makes even the roughest roads smoother, for a more comfortable ride. Shimano's legendarily reliable 3x10 gears give you the range you need to make light work of any route. And Shimano hydraulic disc brakes ensure you can always stop safely, no matter what you're carrying or what the weather is throwing your way. Urban jungle or distant horizon, the Kathmandu Pro has got your back.
Frame description
We've taken everything that's good about the Kathmandu and made it even better. So, for example, the reworked Integrated Carrier 3.0 is designed to work seamlessly with our Acid mudguard. We've fitted a flat mount for the rear disc brake – it also accommodates the kickstand – and used Smooth Welding to give the frame joints a tidy, organic appearance. But it's not all about looks. We also equipped the rear end with a thru axle and added a tapered head tube for improved rigidity and steering precision, even when fully laden. With internal cable routing to keep your gear shifts smooth with minimal maintenance, we reckon we've thought of everything. Just don't forget your toothbrush...
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Aluminium Superlite, Trekking Comfort, Integrated Carrier 3.0, Double Butted |
| Fork | SR Suntour NCX D LO Air, 63mm, Lockout |
| Headset | VP Integrated, Top 1 1/8", Bottom 1 1/2" |
| Stem | CUBE Performance Stem Pro, 31.8mm |
| Bars | CUBE Comfort Trail Bar, 660mm |
| Front Brake | Shimano BR-MT200/UR300, Hydr. Disc Brake, PM/FM (160/160) |
| Rear Brake | Shimano BR-MT200/UR300, Hydr. Disc Brake, PM/FM (160/160) |
| Front Mech | Shimano Deore FD-T6000, Top-Swing, 31.8mm |
| Rear Mech | Shimano XT RD-T8000, 10-Speed |
| Shifters | Shimano Deore SL-M6000, Rapidfire-Plus |
| Speed | 30 |
| Rims | CUBE ZX20, 32H, Disc |
| Front Hub | Shimano DH-3D37, Hub Dynamo, QR, Centerlock |
| Rear Hub | Shimano FH-MT400, 12mm, Centerlock |
| Front Tyre | Schwalbe Range Cruiser, Active, 47-622 |
| Rear Tyre | Schwalbe Range Cruiser, Active, 47-622 |
| Seat Post | CUBE Performance Post, 27.2mm |
| Saddle | Natural Fit Sequence Comfort |
| Chainset | Shimano FC-T551, Hollowtech II, 48x36x26T, 175mm, Integrated BB, Chainguard |
| Chain | KMC X10 |
| Cassette | Shimano CS-HG500, 11-34T |
| Pedals | ACID PP Trekking |
| Weight | 15.7 |
Cube Kathmandu 2023 Size Chart
|
Frame Size |
Height (cm) |
Height (feet) |
|
XS (46cm) |
165 - 170 |
5’5” – 5’7” |
|
S (50cm) |
170 - 175 |
5’7” – 5’9” |
|
M (54cm) |
175 – 180 |
5’9” – 5’11” |
|
L (58cm) |
180 - 190 |
5’11” – 6’3” |
|
XL (62cm) |
190 - 195 |
6’3” – 6’5” |
What size frame do I need if I am between sizes? - read here
