Cube Aim Race Mountain Bike 2025 - Hardtail MTB
The Cube Aim Race offers a dependable ride on trails and beyond. Designed with smooth geometry and integrated features, it’s a bike that grows your skills while delivering comfort and reliability.
Key Features
- Frame: Aluminium Lite, double-butted, Smooth Welded, internal cable routing, confident geometry
- Fork: SR Suntour XCT Disc, 100mm travel, lockout for efficiency on climbs
- Drivetrain: Shimano Cues 10-speed, Rapidfire Plus shifters, wide-range 11-48T cassette
- Brakes: Shimano MT200 hydraulic disc brakes for consistent stopping power
- Wheels: 27.5" or 29” wheels with 2.25” wide CUBE MTB tyres for grip and control
- Other standout feature: Integrated mounts for mudguards, rack, and kickstand
- Finance: Available with 0% APR finance
The Cube Aim Race’s aluminium Lite frame is both lightweight and durable, featuring Smooth Welded junctions for a sleek, premium finish. The internal cable routing not only looks great but also protects cables from dirt and debris, reducing maintenance needs. Its carefully balanced geometry includes a lower top tube, enhancing control and boosting rider confidence, particularly on technical terrain.
The SR Suntour XCT Disc fork provides 100mm of travel to soak up bumps and smooth out trails, and the lockout feature is a handy addition for climbing or riding on flat surfaces. Paired with wide 2.25” tyres, the bike ensures excellent traction and stability on mixed terrain.
Shimano’s Cues 10-speed drivetrain offers a reliable, smooth gear range, perfect for tackling steep climbs and fast descents. The Shimano MT200 hydraulic disc brakes deliver controlled and consistent stopping power in all conditions, giving you extra confidence on the trails.
With features like integrated mounts for mudguards and a kickstand, the Cube Aim Race isn’t just built for adventure but also for everyday practicality. And thanks to Cube’s Size Split system, there’s a frame size to suit riders of all heights, ensuring a comfortable fit for everyone.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Tapered Head Tube, Flat Mount Brake, SIC Mount, FM Kickstand Mount |
| Fork | SR Suntour XCT Disc, 100mm, Lockout |
| Headset | CUBE FPH868p, Tapered, Semi-Integrated |
| Stem | CUBE Performance Stem, 31.8mm |
| Bars | CUBE Rise Trail Bar, 680mm |
| Front Brake | Shimano BR-MT200/UR300, Hydr, Disc Brake, PM/FM (160/160) |
| Rear Brake | Shimano BR-MT200/UR300, Hydr, Disc Brake, PM/FM (160/160) |
| Rear Mech | Shimano Cues RD-U6000-GS, 10-Speed |
| Shifters | Shimano Cues SL-U6000, Rapidfire-Plus |
| Speed | 10 |
| Rims | CUBE EX25, 32H, Disc, Tubeless Ready |
| Front Hub | Shimano HB-QC300, QR, Centerlock |
| Rear Hub | Shimano FH-QC300-HM, QR, Centerlock |
| Front Tyre | CUBE MTB, 2.25 |
| Rear Tyre | CUBE MTB, 2.25 |
| Seat Post | CUBE Performance Post, 27.2mm |
| Saddle | ACID Venec Lite |
| Chainset | Prowheel CC10Y-NW, 32T, 170mm |
| Bottom Bracket | Thun Paso-ML, 73mm BSA |
| Chain | KMC eGlide |
| Cassette | Shimano Cues CS-LG400, 11-48T |
| Pedals | CUBE PP MTB |
Cube Aim Size Chart
|
Size |
Height (cm) |
Height (in) |
|
XS |
150 - 161 |
4’11” – 5’3” |
|
S |
158 - 166 |
5’2” – 5’5” |
|
M |
164 - 178 |
5’4” – 5’10” |
|
L |
176 - 185 |
5’9” – 6’1” |
|
XL |
183 - 191 |
6’0” – 6’4” |
|
XXL |
190 - 195 |
6’3” – 6’5” |
What size frame do I need if I am between sizes? - read here
