Haibike AllMtn 10 2023 - Electric Mountain Bike
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | aluminium, Steckachse M12 (1.00) x 148mm, disc brake Post Mount, Travel: 160mm |
| Fork | FOX 38 Factory Kashima, air, Travel: 160mm |
| Rear Shock | FOX Float X Factory EVOL LV, air |
| Headset | Acros BlockLock |
| Stem | Haibike Components TheStem +++, Bar bore: 31.8mm |
| Bars | Haibike Components TheBar +++ 780mm |
| Front Brake | Shimano Deore XT M8120, 203mm |
| Rear Brake | Shimano Deore XT M8120, 203mm |
| Brake Lever | Shimano Deore XT M8100, aluminium |
| Rear Mech | Shimano Deore XT M8100 Shadow Plus, 12-speed |
| Shifters | Shimano Deore XT M8100, trigger switch |
| Speed | 12 |
| Rims | Mavic E-Deemax Wheelset |
| Front Tyre | Maxxis Minion DHF, 63-622 / Maxxis Minion DHR II, 66-584 |
| Rear Tyre | Maxxis Minion DHF, 63-622 / Maxxis Minion DHR II, 66-584 |
| Seat Post | Dropper-Post Remote, telescope, 34.9mm, aluminium |
| Saddle | fi'zi:k Terra Aidon X5-160 |
| Chainset | Haibike Components, The Crank ++, Aluminium, Haibike Components, Aluminium, 36 teeth |
| Bottom Bracket | UIntegrated |
| Chain | Shimano SLX M7100 |
| Cassette | Shimano M6100, 10-51 teeth |
| Pedals | Freeridepedal aluminium, mit Reflektor |
| Battery Size (WH) | Intube PW X3 720 |
| Motor | Yamaha PW-X3, 250W, 85Nm, 25km/h |
| User Interface | Yamaha Interface - X |
Electric Bike Bike Size Chart
|
Height |
e Bike Size |
e Road Bike Size |
e Mountain Bike Size* |
|
4’8” – 5’1” 143 – 155 cm |
XXS |
44 cm |
13” (33 cm) |
|
5’1” – 5’4” 155 – 163 cm |
XS |
48 cm |
15” (38 cm) |
|
5’4” – 5’7” 163 – 170 cm |
S |
51 cm |
16” (41 cm) |
|
5’7” – 5’10” 170 – 178 cm |
M |
54 cm |
18” (46cm) |
|
5’10” – 6’0” 178 – 183 cm |
L |
56 cm |
19” (48cm) |
|
6’0” – 6’3” 183 – 191 cm |
XL |
58 cm |
20” (51 cm) |
|
6’3” – 6’5” 191 – 196 cm |
XXL |
60 cm |
21” (53 cm) |
|
6’5” – 6’9” 196 – 205 cm |
XXXL |
62 cm |
22” (56 cm) |
* Mountain bikes are sized differently to road bikes. Typically, they are sized in inches as the first MTBs were produced in the USA. European brands like Lapierre and Haibike like to use centimeters for all their bikes. The measurements of their mountain bikes doesn’t match their road bikes but is like a simple conversion from the inches measurement. This is why we have included cm measurements in brackets for the e mountain bike column.
